High Lifter APEXX Polaris RZR PRO XP Upper Radius Bar (Blue) (W/ Bearings)
Description
Description
High Lifter improved the radius bar design even further with our APEXX Suspension Line. In addition to durable, the High Lifter APEXX 2020 Polaris RZR PRO XP Upper Radius Bar (Blue) (w/ Bearings) (HDRB-RZRPRO-1-SB-B6-SBI) with adjustable heim joints and spherical bearings, these radius bars are made with thicker material than stock. Also, added a second bend in the bar to increase the arch, gaining an additional 1.75" of ground clearance over the factory arch.
High Lifter Radius Bars can be differentiated from other aftermarket radius bars by the polyurethane bushings we use. They are firmer than rubber and should last the life of the vehicle. The enhanced performance helps keep the radius bar stable and aims to eliminate excess movement. By greatly reducing movement, the suspension is more efficient and responsive to the driver.
Features
- Crafted from extreme duty 1 ½" x .188" DOM steel construction " 50% larger than average stock radius bars
- Extreme duty spherical bearing housings
- Massive replaceable 7/8" heim joints for camber and tow adjustability without sacrificing strength
- Massive replaceable 7/8" Teflon lined spherical bearings
- 75" of added ground clearance over stock lower radius bar
- Polyurethane bushings to eliminate excess movement
- Simple bolt-on kit
- Powder coated, custom colors available upon request with paint code
- Step by step instructions complete with multi-images for a quick install
- Limited Lifetime Warranty (Excludes wearable items like bearings, cones, and heim joints)
Fitment
- 2020 Polaris RZR PRO XP
- 2020 Polaris RZR PRO XP Premium
- 2020 Polaris RZR PRO XP Ultimate
- 2020 Polaris RZR PRO XP 4
- 2020 Polaris RZR PRO XP 4 Premium
- 2020 Polaris RZR PRO XP 4 Ultimate
Notes
- 2017 Polaris RZR XP 1000 models have two different types of hardware connecting the rear factory radius bars: 10mm or 12mm bolts. Before purchasing radius bars for your 2017 Polaris RZR XP, you need to determine if you have 10mm or 12mm hardware. To determine this will be as simple as finding which socket is used to remove the center bolt holding the radius to the frame. For 10mm hardware you will use a 15mm socket. For 12mm hardware you will use an 18mm socket. This kit does not fit units that have 12mm factory bolts!
