Kolpin Yamaha Bruin Switchblade Snow Plow SystemZoom

Kolpin Yamaha Bruin Switchblade Snow Plow System

Item# KOP-17-00009
$409.95$499.95You Save - $90.00 (18%)
Qty:

Description

Fits All Yamaha Bruin Models

The ATV Kolpin Switchblade Snow Plow System is a complete plow kit, excluding the winch.

It features a robust square tube steel chassis with strategically placed reinforcements for added durability.

Kit Includes:
-(1) ATV Mount Weldment
-(1) Mount LH Bracket
-(1) Mount RH Bracket
-(2) Square U-Bolt, Zinc Plated, M8-1.25 x 50 x 110
-(4) Round U-Bolt, Zinc Plated, M8-1.25 x 40 x 96
-(16) Flange Locknut, Zinc Plated, M8-1.25
-(4) Flat Washer, Zinc Plated, M8
-(4) Spacer, Steel 1.0" Dia. x 0.5" Height
-(2) Hex Flange Bolt, Zinc Plated, M8-1.25 x 65mm LG
-(1) Plate, Steel Strap


Features:
  • Complete Plow-in-a-Box, minus Winch Stamped steel blade technology adjusts to either 48” or 60” width
  • Robust square tube steel chassis with strategically placed reinforcements 5-position blade angle
  • Easy to assemble and install under-body mount Requires winch (sold separately)
  • Assembles in under 1 hour
  • At maximum blade angle position, the snow cutting widths are 43.5” and 54.3” for the 48” and 60” blade widths respectively
  • Product is designed to fit most vehicles, however Kolpin does not guarantee vehicle fitment for all vehicles. See Kolpin.com for the latest vehicle fitment. Always refer to your vehicle’s OEM operator manual to understand warnings and fitment, which takes precedence over Kolpin product instructions and fitment.

    If you are curious about how to install this product, you can view the Install Instructions here.

    This item usually ships in 2-3 business days.
